BigCara's ANH TK AP Build

Recommended Posts

Lense is in, looks great on inside93f2af7174d9fcc95e958af781ec4c6f.jpg

Sent from my SM-A520F using Tapatalk

Share this post


Link to post
Share on other sites

Problem is on the outside, the glue ran and dissolved some of the lenses color into the excess glue which made contact with the white default_sad.png now it looks crap!



Had a test piece that it happened too which cleaned up easily with some sandpaper.



Should I use 1200 grit or go for something finer as need to get the green stain out and clean up the lense scratches



dbe1441a85416577ad6d397803b9d1c2.jpg&key=505d1986b9516442ff95b23377bb5242e11d3b25264edc99883980483df545ab



Sent from my SM-A520F using Tapatalk









  • Like 1

Share this post


Link to post
Share on other sites

It's very hard to get scratches off lens material, you could use some ultrafine sandpaper @2000 grit, or even some cutting polish, may be a little more forgiving

Share this post


Link to post
Share on other sites
It's very hard to get scratches off lens material, you could use some ultrafine sandpaper @2000 grit, or even some cutting polish, may be a little more forgiving
Was thinking the same. Will give it a try, worst case, ripe it out and start again.

Sent from my SM-A520F using Tapatalk

Share this post


Link to post
Share on other sites

Only way to get the scratches out is to buff them out. You can get a buffing bit for a Dremell that usually comes with buffing compound. I have used this to make clear lenses for hengsler counters on the resin Doopy's kits and it works perfectly.

  • Like 1

Share this post


Link to post
Share on other sites

Used some blobs of Apoxie to strengthen around the ear screw holes, which gave me a bit more confidence when counter sinking the screws. Least something turned out ok today :)6510434011cac207d7bc0d725c2328be.jpg0c4a4ceaf47f0f02d6eef11d89296306.jpg

Sent from my SM-A520F using Tapatalk

  • Like 2

Share this post


Link to post
Share on other sites

Polishing the lenses didn't work, so ripped it out and ordered another sheet to cut to size.

Used 600 grit to get rid of the green stains in the sockets, 1200 grit to finish. It came up good as new.acd70c5ecbe768cd864a964c164c4838.jpg

Sent from my SM-A520F using Tapatalk

  • Like 1

Share this post


Link to post
Share on other sites

Sorry to hear it didn't work. Just note you don't need an exact seal on the lenses, having a small gap does allow air to flow and can help with fogging. I found once you are happy with the fitment just to tape in place and add some silicon in a few areas to keep the lens in place, easy to remove an has some flex, just an idea.

Share this post


Link to post
Share on other sites
Sorry to hear it didn't work. Just note you don't need an exact seal on the lenses, having a small gap does allow air to flow and can help with fogging. I found once you are happy with the fitment just to tape in place and add some silicon in a few areas to keep the lens in place, easy to remove an has some flex, just an idea.
Thanks, only a small problem in the scheme of things. Had a gap on the lower edge for air flow. Will try the silicon on next attempt.

Sent from my SM-A520F using Tapatalk

  • Like 1

Share this post


Link to post
Share on other sites

Welding screen arrived yesterday. Lenses cut & installed, brow mesh in, touch up paint done.

Hopefully finish the helmet today, whilst on zoom calls of work :)

With the s trim, is it worth gluing in place or will it hold itself without some spots of glue? As I have seen varying opinions on the forums.9dd2d5dd94b49890fc0ddd90eebc2f36.jpg8e699318cdc89edb9dddfc81e9cec5ec.jpg

Sent from my SM-A520F using Tapatalk

Share this post


Link to post
Share on other sites

Great to see you worked through your little setback.

As to the S trim, make sure you cut it longer than you need and when placing it on feed it around the helmet and really push it in. Mine and I know many others are simply pressure fit in that way and where they do come off sometimes, it's not a frequent occurrence.

You want to make sure once you are getting close to meeting the other end that you have an extra cm or so, so you really need to force it along to get a nice tight fit. if you have too much just trim a touch more off the end but it is surprising how you can cram that last little bit in and it holds firmly in place.

  • Like 1

Share this post


Link to post
Share on other sites
Great to see you worked through your little setback.
As to the S trim, make sure you cut it longer than you need and when placing it on feed it around the helmet and really push it in. Mine and I know many others are simply pressure fit in that way and where they do come off sometimes, it's not a frequent occurrence.
You want to make sure once you are getting close to meeting the other end that you have an extra cm or so, so you really need to force it along to get a nice tight fit. if you have too much just trim a touch more off the end but it is surprising how you can cram that last little bit in and it holds firmly in place.
Thanks Sly11, saw a rs prop masters video of them doing that so will go with your recommendation.

Sent from my SM-A520F using Tapatalk

  • Like 1

Share this post


Link to post
Share on other sites

Buckets back together.

How much can I widen the opening for my big head? doesnt fit in with the trim

73285f1c8bcc880fd8a93c0b18cb9b73.jpgd2c9c242e91e8c57a262d3ec83ff472b.jpg52802be82c8fd26a4aa82a2e7bc74fb9.jpg847fe407361cfdadae7ce6878de4dd40.jpg

Sent from my SM-A520F using Tapatalk

Share this post


Link to post
Share on other sites

This may sound strange, but because of the oval shaped opening many of us have to put our buckets on sideways and then rotate it forward.

  • Like 1

Share this post


Link to post
Share on other sites

Just wanted to check you are putting it on side ways then rotating straight?




gallery_14191_19_8134.jpg.de01f60fa9ef172f068949d0576377af.jpggallery_14191_19_55065.jpg.682a1b4b6bbce101c3d56d91108851cc.jpg

  • Like 1

Share this post


Link to post
Share on other sites
Just wanted to check you are putting it on side ways then rotating straight?




gallery_14191_19_8134.jpg.de01f60fa9ef172f068949d0576377af.jpggallery_14191_19_55065.jpg.682a1b4b6bbce101c3d56d91108851cc.jpg

Yep sideways then rotating, big head



Sent from my SM-A520F using Tapatalk







Share this post


Link to post
Share on other sites
4 hours ago, BigCara said:

How much can I widen the opening for my big head? doesnt fit in with the trim

You can trim off more (a little towards the back and a bit more towards the front).  Take a little bit at a time - a couple of mm can make the difference.



Some of the screen used buckets had quite a bit shaved off the bottom, so you should have no issues.

  • Like 1

Share this post


Link to post
Share on other sites

S trim in on.

Just need to fix 1 decal, add som padding and get some more white paint for the screws.

Can't seem to get the R ear any closer even with targeted sanding. But believe that was ok based on previous posts and being able to drive bus through the gaps in some of the original helmets.34d3dd8c3b713ac1f67c2b4c37e43641.jpg5d73b983eb3077d04929caf499bcacf7.jpg

Sent from my SM-A520F using Tapatalk

  • Like 2

Share this post


Link to post
Share on other sites
7 hours ago, BigCara said:

S trim in on.

Just need to fix 1 decal, add som padding and get some more white paint for the screws.

Can't seem to get the R ear any closer even with targeted sanding. But believe that was ok based on previous posts and being able to drive bus through the gaps in some of the original helmets.

Sent from my SM-A520F using Tapatalk


Looks good! :jc_doublethumbup:

Share this post


Link to post
Share on other sites

Time to finish calves



How's the position of this sniper knee look?



I noticed most AP builds seem to have a slight lean. Will just need heat up one side to push it down slightly.



Should I trim the return edge on the bottom of the knee plate for a closer fit?







8ad39f25d7a222648193df20d16522c7.jpg&key=58d65c9ac0ccb69e4c4cdc49ee4468fb9d5bb7ec087e1c8e3eeb2ed9d5600b9adc9ddf4ba40ed18b638ef35279a611e6.jpg&key=e7293af3f103b1547758ec1cd93859f3c2ed2ee980c60216438233dbbf8b96904fd7a4367108db42df3630dcb9b97871.jpg&key=cfb931008e808b965641e74c58b97d557313a6a8e58ba832853d0d6ba868395d550a4a88a1875cb4257a48a089435e01.jpg&key=10f560799a06f8589cc3752730edf1d4ca9f27bf885074a70422d01b05455457



Sent from my SM-A520F using Tapatalk













  • Like 1

Share this post


Link to post
Share on other sites
8 hours ago, BigCara said:

Time to finish calves



How's the position of this sniper knee look?



I noticed most AP builds seem to have a slight lean. Will just need heat up one side to push it down slightly.



Should I trim the return edge on the bottom of the knee plate for a closer fit?







8ad39f25d7a222648193df20d16522c7.jpg&key=58d65c9ac0ccb69e4c4cdc49ee4468fb9d5bb7ec087e1c8e3eeb2ed9d5600b9adc9ddf4ba40ed18b638ef35279a611e6.jpg&key=e7293af3f103b1547758ec1cd93859f3c2ed2ee980c60216438233dbbf8b96904fd7a4367108db42df3630dcb9b97871.jpg&key=cfb931008e808b965641e74c58b97d557313a6a8e58ba832853d0d6ba868395d550a4a88a1875cb4257a48a089435e01.jpg&key=10f560799a06f8589cc3752730edf1d4ca9f27bf885074a70422d01b05455457



Sent from my SM-A520F using Tapatalk













The positioning looks pretty close.  Trimming the bottom return edge will allow for easier adjustments when you heat it up.  The trick that worked for me is to get it to fit as best you can by heating it up and shaping - then glue one side and let cure for about 48 hours (assuming E6000 is being used).  Then grab a bunch of clamps and glue the other side... it will take some persuasion.



Looking good!

  • Like 2

Share this post


Link to post
Share on other sites

You might want to think about trimming off some more of the bottom of the sniper plate.  This may give you some "wiggle room" to straighten it out a bit as well as reduce the gap between it and the top of the the calf.




  • Like 3

Share this post


Link to post
Share on other sites

Left and right cover strips (25mm) on backs of calves. Going to trim sniper knee now as suggested.5801d828385bb96a014839dbea76faf4.jpg

Sent from my SM-A520F using Tapatalk

  • Like 2

Share this post


Link to post
Share on other sites

Looking good. With the the sniper plate I had to pull mine across so I didn't trim all the return edge of the bottom front, I cut a notch into it so the coverstrip held the plate central.

  • Like 1

Share this post


Link to post
Share on other sites
Looking good. With the the sniper plate I had to pull mine across so I didn't trim all the return edge of the bottom front, I cut a notch into it so the coverstrip held the plate central.
Thanks, this would have been a better solution, but already trimmed. Better fit before trimming but nothing a bath won't fix.

Sent from my SM-A520F using Tapatalk

  • Like 1

Share this post


Link to post
Share on other sites
