  1. I'm an EE technician and do board level repair and debug. I have access to a rework station.
  2. I programmed my BLE device using an FTDI cable and Tera Term terminal emulator. The syntax I used was AT+NAME=TK11055. I discovered after assembly and powering up that the syntax was wrong. Apparently, it should have been AT+NAMETK11055 omitting the “=”. My BLE is named "=TK11055". Too much trouble to change it. I also desoldered the 6 pin header and wired from the thru holes to the pins on the audio adapter. Was a little paranoid about potential shorts between the header pins and the audio adapter. I guess I could of put a piece of shrink wrap around the pins. That would have been easier.
  3. Howdy I built my TKTalkie before SWCO and it worked great. I printed my case using the STL file from your site. I saw you've designed a new case for the BT device. I was wondering if you were going to post the .STL file soon. Thanks Jim
  4. TK- 11055 requesting 501st member access! https://www.501st.com/members/displaymemberdetails.php?userID=25337
  5. where do you store phone
